HydrO2 - Type 1000
HydrO2 - Type 1000
Surface aerator for maximum oxygen input with anti-clogging protection
Additional mechanical and electrical data
- Turbine wheel: 203 mm diameter, 85 mm high, 1.4571 stainless steel (V4A)
- Turbine pipe: 1 m, 1.4571 stainless steel
Coupling: Loewe GK 75 - Bearing: Flange bearing as ceramic bearing material zirconium oxide Zr02, cage PTFE and plastic housing made of PBT type FPL white
Ventilation performance (measured at 1450 rpm)
- Air volume flow: 58, 5 m3/h
- Oxygen input: 5 kg O₂/h
Accessories
- Frequency converter as standard for infinitely variable speed adjustment and energy optimization
Float equipment - Jetfloat© made of Lupolen 5261 (BASF) with holder made of 1.4571 stainless steel (V4A) and feet
Technical data
Here you will find the most important technical data for the HydrO2 – Type 1000.
Further information can be found in the technical data sheets for the HydrO2 – Type 1000 versions.
HydrO2 - Type 1000 | |
---|---|
Engnine | SEW |
Protection class | IP 65 |
Grid frequency | 50 Hz |
Power supply | 230 / 400 V |
Rated power | 2,2 kW |
Net power consumption in water with frequency converter (230 V) at 1450 rpm |
1,6 kW |
Turbine tube length | 1.000 mm |
Total height | 1.490 mm |
Total weight with float and electronics |
124,5 kg |
